设备用途:适用于各种热气溶合防水的产品上

设瀞备功能:热气焊接/溶合

电力要求:单相 AC220V，50HZ/60HZ

额定功率:1.8KW

气压要求:稳定5kg/cm?的气源(不带水气)

熔接温度:800”C

升温保护:1组0.3kg/cm?气压开关(气压低于0.3kg/cm?发热管不升温

熔接速度:1~22m分钟(数字调控)

操作方式:双脚踏(左脚控制上下压轮及剪切两组动作

右脚控制滚轮转动及风枪动作)

风枪规格:25mm固定扁口风咀

上压轮规格:25*58mm(硅胶轮)下鱝吐矞牌賧臯琨栖恓絎鏊狱昨规格:25*58mm(硅胶轮)控制方式:PLC触摸屏控制

滚轮提起高度:0~30mm

电机数量:2组(数字步进电机连驱动器)

净重:115KG 毛重:150KG机氐厕器閪饫尺寸:1200*600*1800mm(长x宽x高)装箱尺寸:1240*670*1620mm1(长x宽x高)

Feature:

Device Purpose: Applicable to various products with

hot air fusion waterproofing.Device Function: Hot air welding/fusionPower Requirement: Single-phase AC220V,50HZ/60HZ

Rated Power: 1.8KwAir Pressure Requirement:Stable air source of 5kg/cm? (without water vapor)Welding Temperature:800"CHeating Protection: 1 set of 0.3kg/cm? air pressureswitch (The heating tube will not heat up when the airpressure is lower than 0.3kg/cm?)Welding Speed: 1 -22m per minute (digitally controlled)Operation Mode:Double foot pedals (The left foot controlsthe up-and-down pressing wheels and two sets of shearingactions, and the right foot controls the rotation of the rollerand the action of the hot air gun)Hot Air Gun Specification:25mm fixed flat-mouthed air nozzleSpecification of Upper Pressing Wheel: 25*58mm (Silicone wheelSpecification of Lower Pressing Wheel: 25*58mm (Silicone wheel)Control Mode:Controlled by PLC touch screenLifting Height of the Roller:0 - 30mm

Number of Motors:

2 groups (Digital stepper motor connected to the driver)N.W. (Net Weight): 115KG G.W. (Gross Weight):150KGMachine Dimensions (W*L*H):

1200*600*1800mm (Length x Width x Height)Packaging Dimensions (W*L*H):

1240*670*1620mm (Length x Width x Height)
